Wednesday, 21 September 2016

Friday, 2 September 2016

Sunday, 14 August 2016

new face

graphite output patching voltage dividers and inputs as magnetised boltheads, magnets underneath graphite strips, and nuts on wires as patch leads.  All the circuitry on the flip-side on an A4 PCB.  HOT!

Tuesday, 9 August 2016

Tuesday, 19 July 2016

Victorian oscillator as percussion and clock

Its a bit scappy at the moment, maybe a capacitor to smooth out the pulse input would help...

Victorian oscillator as clock from michael page on Vimeo.

Friday, 15 July 2016

i made a stereo ring modulator and i have a tiny cat

it has a couple of cheap tricks and is in the happiest tin. The cat is called fen, she has just learnt to ambush

Mike Page at Outpost Studios from michael page on Vimeo.

Friday, 1 July 2016

passive signal router

plug in 3 pedals and switch between signal routes

A-->B-->C
A-->C-->B
B-->A-->C
B-->C-->A
C-->A-->B
C-->B-->A

or A, B & C in parallel

Its totally passive, the double sided PCB is sexy and the only component (other than the jack sockets) is that big switch bank

would a euro rack one of these be useful?


Tuesday, 28 June 2016

record deck clock and sampler w/ master / slave sequencer

a couple of quickly patches to demonstrate record deck clock and sampler w/ master / slave sequencer


record deck clock and sampler w/ master / slave sequencer from michael page on Vimeo.
MVI_0737 from michael page on Vimeo.

Tuesday, 7 June 2016

Monday, 16 May 2016

freehand soldered new sequencer thingy

sequencer thingy. 555 switchable from monostable (so it can be clocked from my turntable sampler thing) or astable to clock itself. the momentary buttons pause and reset the sequence. The jack in the middle lets the sequence be reset by the outside world (drum kit) the row of switches at the bottom are a sort of custom clock, so when they are pushed down they send a pulse (out the jack on the right) to advance a second sequencer for slower musical changes.

Wednesday, 27 April 2016

2 arms and clock from record deck

I have put an extra tone arm and got a clock out from this record deck. The clock out is a reed switch responding to magnets on the bottom the record.
video-1461780595 from michael page on Vimeo.

Friday, 12 February 2016
